Our Holtab Modular Indoor Concept (HMIC) is a prefabricated and cost-effective solution for technical and switchgear buildings. The stations are constructed, manufactured and inspected at our factory prior to delivery.
All installation takes place in a safe, controlled environment – we deliver as close to a plug-and-play solution as you can get.
The building is constructed of high-quality building elements without organic material, to ensure a long service life. The station meets the industry requirements for insulation, fire resistance, corrosion resistance and safety class.
There is a wide range of standard dimensions to choose from, but the station can also be totally adapted to your requirements. The concept is based on 1.2 meter modules and the building can be fitted out using many different options.
You have great flexibility to adapt the station according to your preferences and requirements. The building can be equipped with a variety of standard options such as doors, stairs, entrance roofs, climate control, ventilation, recessed junction boxes, cable ladders, mounting plates for heavy equipment, anti-static floor mats, and more.
A standardized and compact structure suitable for lighter equipment.
Suitable for use as e.g. a SCADA building.
Standard building.
Short delivery time.
EI60
Aluzinc sheet metal with high corrosion resistance.
Equipped with standard general electrical installation as an option.
2.43–7.23 m
2.38 m
2.7 m
2.15 m
2.15 m
2.40 m
Roof with a 5° pitch.
Snow zone 4.5
Wind 34 m/s
C4
IP23D
12 tons, including equipment.
Floor 600 kg/sqm
Examples of optional extras
Colour: light grey, anthracite grey, green-grey, forest green, red
Electrical installation: general electrical standard
AC
IT rack
Roxtec cable entries (floor)
Skirts
