E-site Dual 2x1 600 kVA
When the required capacity is higher, a single transformer isn’t always enough. E-site Dual delivers up to 2 × 1 600 kVA with a strong focus on operational reliability and personal safety—and meets the requirements of IBH 24 as well as enabling connection of customer installations of 1–36 kV to the power grid.
Modular solutions for maximum flexibility
We have a broad portfolio of modular and scalable solutions for compact secondary substations (CSS). Using steel and concrete as construction materials, we build safe and robust compact secondary substations (CSS).
Customised solutions
Solutions customised to requirements.
Plug and play
Minimises installation time on site.
Personal safety
Designed and tested with a focus on safety for the installer and surroundings.
Digitalisation
Digital solutions for metering, communication and automation.
According to standard
The stations fulfil the current IEC 62271-202 standard.
Customer site
Meets the requirements of IBH 24. Connection of customer installations 1-36 kV to the electricity grid.
Compact secondary substation (CSS) with 3xRMU switchgear and double transformer
- Compact secondary substation (CSS) in aluzinc with steel foundation.
- RMU medium-voltage switchgear 12-24 kV.
- Transformer oil insulated/dry insulated up to 1,600 kVA.
- Modular low-voltage switchgear HMS up to 2500 A.
- Designed and type tested according to standard IEC 62271-202.
- Arc-proof IAC-AB 20 kA 1s.
- Holtab’s metering cabinet for high-voltage measurement incl. CT/VT.
- Meets the requirements of IBH 24. Connection of customer installations 1-36 kV.
- Available in any colour and exterior design option.
